Architecture

SCADERIS Scheduler consists of 3 components:

• A Scheduler Processor service that executes scheduled tasks and includes an OPC-UA server
• A Scheduler Dashboard service that runs a web server for the user interface
• A Microsoft SQL Server database

These 3 components must be installed on Windows Server or Windows Client operating systems.

These 3 components can be installed on 3 separate operating systems (3 different machines).
